Connector Style
IEC 320-C14
Connector Type
Receptacle, Male Blades – Module
Current Rating – Appliance Inlet
1A
Voltage Rating – Appliance Inlet
250VAC
Filter Type
Filtered (EMI, RFI) – Commercial
Current Rating – Filter
1A
Current Rating – Circuit Breaker
–
Accomodates a Fuse
Yes (Fuse Not Included)
Mounting Type
Panel Mount, Flange
Termination
Quick Connect – 0.189″ (4.8mm)
Features
Voltage Selector
Fuse Holder, Drawer
Drawer Sold Separate
Panel Cutout Dimensions
Rectangular – 28.60mm x 50.00mm
Material Flammability Rating
UL94 V-0
Approval Agency
cULus, ENEC
