Arrays

CDRCH12D78BNP-330MC

Manufacturer

Category

Arrays, Signal Transformers
Mfr. Part #

CDRCH12D78BNP-330MC
Description

INDUCT ARRAY 2 COIL 33UH SMD
Details Description

Shielded 2 Coil Inductor Array 132 µH Inductance – Connected in Series 33 µH Inductance – Connected in Parallel 72mOhm Max DC Resistance (DCR) – Parallel 2.7 A Nonstandard
Package

Nonstandard
In Stock

15208

Datasheet: datasheet

Contact us

WhatsApp: +86-18123905375

Wechat: +86-18123905375

Email: sales@printedcircuitboardassy.com

Free Quote

Mfr
Sumida America Components Inc.
Series
CDRCH12D78B
Package
Tape & Reel (TR)
Product Status
Active
Number of Coils
2
Inductance – Connected In Parallel
33 µH
Inductance – Connected In Series
132 µH
Tolerance
±20%
Current Rating – Parallel
2.7 A
Current Rating – Series
1.3 A
Current Saturation – Parallel
5.5 A
Current Saturation – Series
2.75 A
DC Resistance (DCR) – Parallel
72mOhm Max
DC Resistance (DCR) – Series
290mOhm Max
Shielding
Shielded
Ratings
–
Operating Temperature
-40°C ~ 125°C
Mounting Type
Surface Mount
Package / Case
Nonstandard
Size / Dimension
0.480″ L x 0.480″ W (12.20mm x 12.20mm)
Height
0.315″ (8.00mm)
