Connector Style
IEC 320-C14
Connector Type
Receptacle, Male Blades – Module
Current Rating – Appliance Inlet
–
Voltage Rating – Appliance Inlet
–
Filter Type
Filtered (EMI, RFI) – Commercial
Current Rating – Filter
10A
Current Rating – Circuit Breaker
–
Accomodates a Fuse
Yes (Fuse Not Included)
Mounting Type
Panel Mount, Snap-In
Termination
Quick Connect – 0.250″ (6.3mm)
Fuse Holder, Drawer
Fuse Holder
Panel Cutout Dimensions
Rectangular – 29.50mm x 33.00mm
Panel Thickness
0.024″ ~ 0.059″ (0.60mm ~ 1.50mm)
Material Flammability Rating
UL94 V-2
Approval Agency
CQC, CSA, ENEC, UL
Base Product Number
FN261
