Connector Style
IEC 320-C14
Connector Type
Receptacle, Male Blades – Module
Current Rating – Appliance Inlet
10A
Voltage Rating – Appliance Inlet
250VAC
Filter Type
Filtered (EMI, RFI) – Commercial
Current Rating – Filter
6A
Switch Features
Switch On-Off
Current Rating – Circuit Breaker
–
Accomodates a Fuse
Yes (Fuse Not Included)
Mounting Type
Panel Mount, Snap-In
Termination
Quick Connect – 0.189″ (4.8mm)
Fuse Holder, Drawer
Drawer Sold Separate
Panel Cutout Dimensions
Rectangular – 28.80mm x 47.80mm
Panel Thickness
0.039″ ~ 0.098″ (1.00mm ~ 2.50mm)
Material Flammability Rating
UL94 V-0
Approval Agency
CCC, cULus, ENEC
Base Product Number
KMF1.1161
